Thermo Gravimetry/Differential Thermal Analyzer (TG/DTA)


Instrument Details



Make: PERKIN ELMER
Model Specification: Diamond TG/DTA



Thermo Gravimetry/Differential Thermal Analyzer


Working Principles



Thermal behaviour being one of the physical property of any material, it gives fair estimation of constituents, nature and usage of material. The traditionally adopted procedures for thermogravimetry and calorimetry are tedious, time consuming and involve elaborate human intervention. Modern thermal analysing systems overcome all the problems associated with the traditional techniques as they use versatile computers for setting up of experiment, its control, data acquisition/storage and analysis. Further, use of electronic sensors for physical measurements increase the sensitivity, accuracy and ease of operation.

Schematic of focused ion beam system showing beam path from source through doping cell to sample with control electronics.



Applications



  1. Compositional analysis
  2. Heat of Transition
  3. Oxidative and Thermal stabilities


User Instructions



  1. User must specify the type of analysis that he/she may want to perform.
  2. User must specify like temperature range.
  3. Only solid state samples are analyzed that may exists in the form of Film, Foil, Powder, Polymer.
  4. User must submit the requisition duly filled in and signed by their respective supervisors to the concerned person.
  5. External User can contact with the concerned person through e-mail or in person.
  6. External User must submit the requisition form for external users duly filled in and signed by their respective supervisors to the concerned person

Payment Instruction:



  1. A Requisition letter addressing In-charge Technical cell along with
  2. Demand Draft in favour of S. N. Bose National Centre for Basic Sciences."
  3. Cash payment after completion of the expt.
  4. Payment through Debit/Credit Card
  5. Wire transfer details  (see below details)


Contact Us



033 2335 5706/5707/5708, Extension:  264




Thermo Gravimetry/Differential Thermal Analyzer (TG/DTA) Charges


University /College [1] National Lab/ R&D Industry[1]
TG/DTA Charges ₹500/- ₹500/- ₹1500/-





[1] Per sample or per hour whichever is greater (in ₹ )



The Demand Draft should be in favour of "S. N. Bose National Centre for Basic Sciences."
Letter, DD & Samples send to "Technical cell, S. N. Bose National Centre for Basic Sciences, Kolkata- 700106



[2] Money Transfer Information:



National Electronic Fund Transfer (NEFT) Details for Money Transfer

  1. Name of the Account Holder: S. N. Bose National Centre for Basic Sciences

  2. Bank Account Number:089302000000220

  3. Type of Account: Current Account

  4. Bank Name: Indian Overseas Bank

  5. Branch Name: Salt Lake City Branch

  6. Complete Address of Branch: Block - EA, Salt Lake City, Sector - 1, opp. Labony Estate, Kolkata - 700064.

  7. IFS Code of the Branch:IOBA0000893
